◆Measurement time: 30L/min
◆Measurement accuracy: 80-100g
◆Quantity of auxiliaries: 10 kinds (after site)
◆Measurement method of distribution: rotor pump, capacity measurement method
◆Charging: diaphragm pump, 40L/min, lift: 10 meters.
◆Number of connecting machines: 5 units (after site)
◆Special liquid additives, viscosity: 500cp
◆Measurement range: 750g~650kg
◆Energy Conditions Water Pressure: 3kg/cm 2 above steam: 2kg/cm 2 above air pressure: 5kg/cm 2 above power supply: 3, AC220V, 5KW
◆Specification: 2700mm (W) *950mm (H) *1900mm (D)
◆Storage tank: 0.5 tons or 1 tons of corrosion-resistant and acid resistant plastic cans (or stainless steel cans)
◆The liquid level is displayed intuitively on the display screen of the main cabinet. The automatic liquid level signal acquisition (detection) and feedback control ensure the liquid level in the effective range.
◆All pipes are made of SUS316L, stainless steel pipe diameter_25, and the inside of the pipe is polished.
◆The distribution of auxiliaries is divided into T type pneumatic valves, and pneumatic components are imported components.
◆In view of the large amount of water added, corresponding water feeding branches corresponding to each machine charging bucket have corresponding branches. Using single flowmeter metering to achieve simultaneous metering of auxiliaries and water, and increase the efficiency of distribution.
◆Delivery speed: 30-60L/min
◆Measurement accuracy: 50-80g
◆Number of auxiliaries: N species (after consultation with customers)
◆Measurement method of distribution: rotor pump, capacity measurement method
◆Charging: diaphragm pump, 40L/min, lift: 10 meters.
◆Number of connecting machines: N (after site)
◆Special liquid additives, viscosity: 500cp
◆Measurement range: 500g~650kg
◆Energy Conditions Water Pressure: 2kg/cm 2 above steam: 4kg/cm 2 above air pressure: 6kg/cm 2 above power supply: 3, AC220V, 5KW
◆Specification: 2700mm (W) *950mm (H) *1900mm (D)
◆The system adopts bus type pipeline design, that is, the distribution of various auxiliaries by a pipeline.
◆High speed pump transmission, pipeline layout is exquisite, no residual AIDS, easy to wash, good results.
◆Unified management of auxiliary usage report, auxiliary storage and storage.
◆With variable frequency control and professional titration design, the accuracy of distribution is high.
◆Seamless connection between SQL SERVER database system and dyeing plant ERP
